Thyro S 2S Series 2 Leg 3 Phase SCR Controller 16 - 1500Amp 400VAC 10/-15% Burst(TAKT) Fire Mode, Economical Firing Mode
Thyro S 2S Series 2 Leg 3 Phase SCR Controller 16 - 1500Amp 400VAC 10/-15% Burst(TAKT) Fire Mode, Economical Firing Mode
Thyro S 2S Series 2 Leg 3 Phase SCR Controller 16 - 1500Amp 400VAC 10/-15% Burst(TAKT) Fire Mode, Economical Firing Mode

Thyro S 2S Series 2 Leg 3 Phase SCR Controller 16 - 1500Amp 400VAC 10/-15% Burst(TAKT) Fire Mode, Economical Firing Mode

$ 55.52

$ 72.18

Save: $

Current Rating 45 Deg C:
  • 16 Amp
  • 30 Amp
  • 45 Amp
  • 60 Amp
  • 100 Amp
  • 130 Amp
  • 170 Amp
  • 280 Amp
  • 350 Amp
Load Monitoring/Control:
  • U
  • H3 - U
  • P
  • I
  • HRLP3 - U
  • HRL3 - U
Unavailable
Please select combo product attributes
The combo subtotal is $,SAVE$

Product Details

Advanced Energy Thyro S 2S Series 2 Leg 3 Phase SCR Power Controller, Burst(TAKT)Firing Mode Only. Compatible Replacement for Eurotherm

Features

  • 400VAC 10/-57% Line to Line Voltage, Current or Power Control
  • Smallest footprint on the market
  • Built in Fuses
  • 3 Phase, 2 Leg Economical Burst Controller Firing Mode
  • (0)4-20mA, 0(1)-5V, 0(2)-10V or POT input Proportional Control
  • Removable Cover
  • USB Configuration/Bias Setting
  • Potentiometer Adjustment
  • Synchronisation Function

Applications

  • Electrical Ovens, Kilns, or Furnaces
  • Primary Control of Transformer Loads in Phase or Burst Fire mode
  • Resistive Loads up to 6:1 Hot/Cold Ratio
  • AC Soft Starter (Combined with PLC)
  • Power Regulation Applications
  • Electric Boilers
  • Brewery Heating
  • Industrial Light Dimming
  • Suitable for extreme environments such as mining

Series Optional Features

    For HRL

    • Current Control/Feedback
    • Programmable Relay Alarm Output
    • Load Monitoring
    • Analogue Output

    For HRLP

    • As above with Power Control Feedback

    Communication Options



      Specification
      Advanced Energy Part Number Thyro S 2S 400VAC
      Approvals CE, UL508A, EU Directive 2014/35/EU & 2004/108/EC
      Control Accuracy 3% at rated voltage
      Rated Operating Temperature 45°C
      Temperature Derating 0.9 x Inom @ 50 Deg C, 1.1 x Inom @ 35 Deg C
      SCR Configuration Single Phase AC Switch
      Control Modes 2 Leg Burst(TAKT) for low dissipation
      Control Input 4(0)-20mA, 0(1)-5V, 0(2)-10V, POT
      Load Current 16 to 1500 Amp @ 45 Deg C (110% @ 35 Deg C Max)
      Control Range 0-100%
      Options Conformal Coating for Gas or High Humidity Environments
      Mounting Style Panel Mount
      Supply Voltage Range 400VAC 10/-15% (-57% with 24VDC Aux Supply)
      Soft Start Via PLC input
      Termination Style Screw
      Unit Weight 2.1 to 74kg
      Factory Pack Qty 1



      Technical Docs
